H-Base Davit Arm Claimed

AFT751011-H-Base Davit Arm

AFT751011-H-Base Davit Arm

FEATURES:

  • The Extreme H-Base Davit breaks down into five components for easy storage, transport, and set-up. No tools are required for assembly.
  • The modular design allows the use of various fixed and portable bases and an optional mast with extensions.
  • The cantilever arm comes with 3 adjustment positions for the user to adjust the height as per the requirement.
  • An ideal choice is to provide overhead anchorages in large holes of confined space.
  • Foldable legs for easy transportation and installation purpose.
  • Multi anchorage point for rescue purposes.
  • Inbuilt swivel feature, Davit column assembly can be rotated up to 360° by removing the locking pins provided to the lock column and H-Base.

Part Number: AFT751011

Description

MATERIAL:

High Strength and Durable Aluminum Alloy

MIN. & MAX. OPENING OF H BASE:

Ø1100 mm – Ø1510 mm

MAXIMUM LOAD CAPACITY:

500 kgs

FINISH:

ED Coated

SYSTEM STRENGTH:

15kN

CERTIFICATION:

EN 795:2012 Type B & AS/NZS 5532:2013

WEIGHT:

62.56kgs ± 0.10kgs
